The JA-154M wirelessly transmits up to two independent closed / open states to the JABLOTRON 100+ system from devices with a potential-free output: external magnetic contacts, push buttons or relay outputs of other systems. With its built-in magnetic sensor, the detector also works as a standard door and window opening detector.
Compared with the <a href="https://portal.jablotron.com/p/ja-150m" target="_blank" rel="noopener noreferrer">JA-150M</a>, it brings:
<ul>
 <li>asynchronous communication with no DIP switches; all settings are made in F-Link,</li>
 <li>a plug-in terminal block for faster cable connection,</li>
 <li>a new tamper contact position, so the contact is not pressed by accident during installation and does not cause false alarms.</li>
</ul>
Typical applications:
<ul>
 <li>garage doors with the <a href="https://portal.jablotron.com/p/sa-220" target="_blank" rel="noopener noreferrer">SA-220</a> contact, swing and sliding gates with the <a href="https://portal.jablotron.com/p/sa-204" target="_blank" rel="noopener noreferrer">SA-204</a> contact,</li>
 <li>concealed drill-in contacts <a href="https://portal.jablotron.com/p/sa-210" target="_blank" rel="noopener noreferrer">SA-210</a> and <a href="https://portal.jablotron.com/p/sa-211" target="_blank" rel="noopener noreferrer">SA-211</a> in windows and doors,</li>
 <li>renovations: connecting an older contact built into a window where no cable can be run to the control panel,</li>
 <li>the <a href="https://portal.jablotron.com/p/ct-01" target="_blank" rel="noopener noreferrer">CT-01</a> roller shutter sensor to detect tampering with external roller shutters,</li>
 <li>the <a href="https://portal.jablotron.com/p/ld-81" target="_blank" rel="noopener noreferrer">LD-81</a> flood sensor in inaccessible places (for example behind a wall-hung toilet frame or a bathtub panel),</li>
 <li>a level switch in a tank or sump, outputs of CCTV, fire or access control systems, a doorbell button or an evacuation button.</li>
</ul>
Instead of triggering an alarm, the input state can be shown for information only through a PG output on the keypad or in the MyJABLOTRON app, for example an open garage door.
In F-Link, inputs IN1 and IN2 can be set to enabled, single or double balanced (1 kΩ resistor), roller shutter mode, <a href="https://portal.jablotron.com/p/ld-81" target="_blank" rel="noopener noreferrer">LD-81</a> flood mode or pulse mode. An external tamper contact is connected to the TMP input, for example on a distribution box door. Up to two <a href="https://portal.jablotron.com/p/ld-81" target="_blank" rel="noopener noreferrer">LD-81</a> flood sensors can be connected.
The package contains two magnets: a large ferrite magnet in a plastic cover and a small neodymium ring. After enrollment, the detector occupies three positions: the built-in magnetic sensor, input IN1 and input IN2. Unused positions can be removed. The system must include a JA-11xR radio module for enrollment. The detector is designed for indoor use. The product can be installed by a certified technician with a valid certificate issued by an authorized distributor.

A magnetic opening detector with two independent universal inputs for external sensors with a potential-free output. It replaces the JA-150M and now uses two-way asynchronous communication.
