Name: Wireless PIR motion detector
SKU: JA-154P
Price: *** EUR
Availability: InStock

In stock

The detector utilises advanced digital signal processing and two-way asynchronous communication, ensuring excellent immunity and detection stability in various types of indoor installations.

<ul>
<li>High detection reliability: The detection characteristics cover an angle of 90° with a range of up to 12 metres, while digital signal filtration minimises the risk of false alarms.</li>
<li>Two-way communication: The use of an asynchronous protocol increases data transmission security and enables efficient power management. All detector settings are managed via configuration software; this eliminates the need for site visits or opening the cover to access setting switches.</li>
<li>Optimised power supply: The detector is powered by two 1.5 V AA alkaline batteries with a typical service life of approximately 5 years, reducing regular maintenance requirements.</li>
<li>Suitable mounting: The recommended installation height is 2.2 to 2.5 metres above floor level.</li>
<li>Comprehensive protection: The device is equipped with tamper contacts that immediately signal the opening of the cover or the removal of the detector from the wall.</li>
<li>System compatibility: The module is fully supported by the <a href="https://portal.jablotron.com/p/JA-102KY" target="_blank">JA-102K</a>, <a href="https://portal.jablotron.com/p/JA-103K" target="_blank">JA-103K</a> and <a href="https://portal.jablotron.com/p/JA-107K" target="_blank">JA-107K</a> series control panels, as well as <a href="https://portal.jablotron.com/p/JA-152KRY" target="_blank">JA-152KRY</a> wireless variants.</li>
<li>Certified security: The product is certified to Security Grade 2 according to the European EN 50131 standards.</li>
</ul>

Thanks to its compact dimensions and timeless design, the detector blends inconspicuously into any interior without appearing intrusive. To ensure optimal performance, we recommend avoiding installation near heat sources (radiators) or in areas with intense air circulation (draughts).

Wireless PIR motion detector

Colour

Product type

System

The JA-154P is a modern wireless PIR motion detector designed for the protection of standard interiors. It detects the movement of persons within a monitored area with high resistance to false alarms. The product represents a full replacement for the older JA-150P model and is designed for reliable operation within the JABLOTRON 100+ and Mercury systems.
