F-LINK SOFTWARE UPDATE: New version 3.0.4

Grade 3, new hardware and a range of fixes

Version 3.0.4 expands support with the JA-108K control panel, a full set of settings for the EN 50131-1 grade 3 standard, new peripherals, and fixes a number of bugs that could affect configuration accuracy or the behaviour of the graphical interface.

What's new?

JA-108K support

The JA-108K control panel is now fully integrated into F-Link — including the EN 50131-1 Grade 3 system profile and all accompanying peripheral and system parameter settings.

EN 50131-1 Grade 3 support

The new version introduces a complete system profile for Grade 3 on the JA-108K. It includes:

• Configuration of peripherals JA-116E, JA-111H TRB, JA-113A and JA-113M to meet the requirements of the standard
• Monitoring of the minimum required peripheral firmware version
• Restriction of PCO settings and system parameters of the control panel to comply with the profile
• New system events:
  • High voltage or current draw on the bus
  • Recording of configuration write failures
  • Recording of "Unknown user" in case of invalid authorisation
• Insurmountable obstruction when exiting service mode if an antimasking fault is active on a detector connected via JA-111H TRB
• New behaviour when the maximum number of invalid code login attempts is exceeded
• Low residual energy indication in JA-113A diagnostics
• Prohibition of use of identification cards and tags for users
• New settings section "Advanced settings" in the Parameters tab

New peripherals: JB-112TH and JB-112TP

F-Link 3.0.4 now supports CO₂-measuring thermostats — JB-112TH and JB-112TP.

Minor configuration improvements

• JA-151R: new parameter "Connection without battery"
• Additional information added in the authorisation element learning dialog when learning MIFARE-standard elements by presenting a tag
• JA-156J: parameters "Optical signalling" and "Acoustic signalling" have been merged into one — "Optical and acoustic signalling"; a "Button press signalling" parameter has also been added

What's fixed?

Factory values and default settings

• JA-112J: incorrect factory value of the "PG control" parameter corrected to "PG on/PG off"
• JB-128N: factory values for PG outputs and pump protection and anti-freeze protection parameters corrected
• JB-111TH, JB-111TP, JB-151TH, JB-151TP: incorrect default thermostat values and display in non-Czech language versions corrected
• JA-112M: settings updated in the EN 50131-1 Grade 2 and Incert profile
• JA-111H AD TRB: parameters "TMP input" and "LED indication" corrected

False incompatibility reports

• JA-110R-80 and JA-111R-80 incorrectly reported incompatibility
• JA-121PB incorrectly reported incompatibility in JA-101K and JA-106K control panels
• Invalid "Settings do not meet the selected profile" message when exiting service mode on systems with the default profile

User interface fixes

• JA-156J, JA-157J, JA-154J MS II, JA-152J MS II: schematic icons and object map icons corrected
• JA-162M: alignment of DIP switch display in the internal settings preview
• Segment keypads: corrected swapping of A/B lock display on mouse hover
• Firmware update dialog: persistent "Always on top" priority removed — other windows can now correctly be brought to the foreground
• Update loop on a new factory-fresh control panel — fixed
• Incorrect event ordering in the Events from memory dialog — fixed
• Incorrect LED indication settings for JA-111R, JA-112R, JA-151R — fixed
