It enables radio connection between the control panel and wireless peripherals, such as detectors, keypads, sirens, remote controls, output modules, etc. Up to 3 radio modules can be connected to a single control panel. This ensures reliable internal radio communication coverage even in large buildings or across wide external perimeters.

<ul>
<li>The product is a modernised successor to the <a target="_blank" href="https://portal.jablotron.com/p/JA-111R">JA-111R</a> module. It retains the same dimensions and installation procedures.</li>
<li>The package contains the PCB itself and a connection cable. When retrofitting into a JA-102K, JA-103K, or JA-107K control panel, the PCB is mounted into the prepared holder (included with the control panel) and connected to the panel using the supplied 4-pin connection cable.</li>
<li>For control panels designated <a target="_blank" href="https://portal.jablotron.com/control-panels">JA-10xKR</a>, the radio module is factory-fitted and does not need to be ordered separately, unless the scope of the installation requires multiple radio modules.</li>
<li>The module can also be installed anywhere indoors where the system bus is available. When installed outside the control panel, the module must be fitted into the <a target="_blank" href="https://portal.jablotron.com/p/PLV-JA111R">PLV-JA111R</a> installation kit (sold separately; the kit includes a plastic cover and a terminal block for the bus connection).</li>
</ul>

Wireless peripherals can only be assigned within the range of positions 1 to 120. PG output statuses can only be transmitted wirelessly between the control panel and peripherals within the range of PG 1 to 32. Other peripheral positions and PG outputs only support bus communication.

Bus module for connecting JA-100 wireless components

The module provides an internal communication interface between the wired bus and the wireless elements of the JABLOTRON 100+ and Mercury systems.
 The product is only compatible with JA-102K, JA-103K, and JA-107K control panels and the new JA-151R repeater (it is also compatible with the older JA-150R repeater).
