GSM Control panel with LAN and radio module

The required adjustments and sizing of the system are programmed through the F-Link software (from version 2.0.0).
The JA-103K control panel offers:
<ul>
<li>50 wireless or bus devices</li>
<li>50 users</li>
<li>8 sections</li>
<li>32 programmable PG outputs</li>
<li>20 mutually independent calendar events</li>
<li>8 user SMS and voice reports</li>
<li>5 ARCs can be set</li>
<li>5 selectable protocols for an ARC</li>
</ul>
The control panel has:
<ul>
<li>1 terminal board for bus connection</li>
<li>1 connector for a built-in radio module (JA-111R)</li>
<li>1 connector for a GSM/GPRS communicator (JA-192Y)</li>
</ul>
The control panel also offers functions such as:
<ul>
<li>Maintenance</li>
<li>Day/night mode</li>
<li>Short departure response</li>
<li>Automatic setting</li>
<li>Advanced calendar features</li>
</ul>
<hr />
The following products with the control panel ARE NOT COMPATIBLE:
<ul>
<li>JA-180A (wireless outdoor siren)</li>
<li>JA-154J (bi-directional remote control)</li>
<li>JA-190X (PSTN communicator module)</li>
</ul>
 The following products with the control panel ARE COMPATIBLE under certain conditions:
<ul>
<li>The JA-112E (keyboard) is compatible with FW LU61501 and higher</li>
<li>The JA-113E (keyboard) is compatible with FW LU61601 and higher</li>
<li>The JA-118N (PG Bus Output Module) is compatible with LY68003 and higher
<ul>
<li>FW version LY68002 and lower works only when the PG range is set in the F-Link up to a maximum value of 32</li>
</ul>
</li>
<li>The JA-110I (section or PG bus indicator) is compatible only when the PG range is set in the F-Link up to a maximum value of 32</li>
</ul>

GSM Control panel with LAN communicator

System

The core element of the JABLOTRON 100+ security system. A control panel for protecting family houses, offices and smaller companies. It can only be installed by a trained technician with a valid JABLOTRON a.s. certificate.
